10,000W Wind Turbine Control Panel with Charge Controller, Dump/Divert Load, Brake, Plug and Play

SKU:
722208356634
$3,249.00
(No reviews yet)
Current Stock:
Adding to cart… The item has been added

This panel is pre-wired and ready to go!  Hook up your turbine and battery and absolutely no additional wiring is needed!

Features:

  • Totally pre-wired and ready to go: Connect battery and up to a 10,000W 3 phase AC wind turbine generator
  • White powder coated steel UL listed panel made in USA.  Recessed or surface mounting options.
  • Includes panel cover plate, which allows the entire enclosure to be closed safely with no exposed wiring.
  • Aluminum dump load resistors run cooler and last longer than traditional ceramic resistors while still dissipating 300W each.
  • Automatic temperature controlled fans for cooling dump load resistors and solenoid relay.
  • Includes panel cover plate, which allows the entire enclosure to be closed with no exposed wiring. Safe and easy to use.
  • Wind turbine brake with 3 Phase AC input connectors ready to connect wind turbine.
  • Rectifier with active cooling converts 3 phase AC input to DC battery charging voltage.
  • Extra space for mounting YOUR devices like timers, power meters, and other control equipment.
  • DIN rail mounted components for easy customization.
  • Completely assembled and quality checked in USA.
  • Perfect for off-grid installations at home, industrial use, commercial use, etc.

Specifications:

  • Max battery quantity: none
  • Minimum battery recommendation: 12kWh
  • Max wind turbine power: 10,000W
  • Wind turbine power input: 3 phase "wild" AC
  • Dimensions: 42"H x 14-1/4"W x 3-5/8"D
  • Weight: 98.6 lbs
