Solar Panel Wall Wire / Cable Entry Weatherproof with Single or 2 Gang Outlet Box

$99.00 - $199.00
(2 reviews)
Shipping:
Free Shipping
Current Stock:
Adding to cart… The item has been added

The original and genuine RevoPower solar panel cable entry housing is one of our most popular solar products! Our solar panel weatherproof cable entry is perfect for speeding up your next solar project! Ideal for routing the cables through a wall, soffit, roof, or any other surface.

Beware of imitations with inferior components and low quality connectors. Our solar cable entry housing is a reliable and long-lasting solution for your solar panel installation needs. With 5 years of meticulous design and testing behind it, you can trust that our housing will outlast and outperform the competition. Say goodbye to worries about durability and hello to a hassle-free and efficient solar panel system with our top-quality cable entry housing.

This cable entry housing is designed to be used with any standard single or 2 gang electrical outlet box and includes a standard single or 2 gang box. It can be used vertical or horizontal.

Top Features:

  • High Performance Specifications: Maximum voltage capacity 600V. The maximum current per connector pair is 44A.
  • Regulatory Compliance: Meets the 2014 NEC handbook 690.33(C) requirements, featuring a self-locking design with a tool-required unlock mechanism (unlocking tool included). Also meets all 2008/2011 NEC handbook requirements.
  • Superior Durability: With 5 years of dedicated design and testing, our cable entry housing boasts exceptional longevity and reliability, outperforming imitations with inferior components.
  • Weatherproof and Versatile: Perfect for routing cables through various surfaces, including walls, soffits, and roofs, offering a weatherproof solution to protect your solar panel system.
  • Complete Kit Included: Comes with a pre-assembled black plastic housing, pre-wired solar panel connectors with 6" long 10 AWG wire, WAGO connectors, an outlet box (single or 2 gang), and a gasket for the outlet box.
  • Indoor/Outdoor Adaptability: Rated for both indoor and outdoor use, demonstrating exceptional weather resistance and versatility.



Includes:

  • 1 Pre-assembled black plastic housing.
  • Pre-wired solar panel connectors (6" long 10 AWG wire) and WAGO connectors for easy wire connection.
  • Solar panel connectors installed and wired, rubber gaskets installed.
  • Outlet box. (Single, or, 2 gang)
  • Gasket for outlet box.

Specifications:

Wire lead length: 6"
Wire lead size: 10AWG
Max Voltage: 600V
Max Current (Per Connector Pair): 44A
Operating Temperature Range: -40°F (-40°C) to 131°F (55°C)
Connector O-ring Type: 3/32" Thick Silicone
Connector Type: Amphenol H4, UL 6703 with Machined/Cold Formed Contacts, Copper/Tin Plated, IP68

Meets 2014 NEC handbook 690.33(C), requirement for self-locking with tool-required unlock. Unlocking tool included.

Meets all 2008/2011 NEC handbook requirements
Country of Origin: Housing: USA
Wire: USA
Connector: China
Environment rating: Indoor/Outdoor Weather resistant



Reviews

  • 5
    Is as expected

    Posted by jrh1959a on 16th Oct 2024

    Is as expected

  • 5
    Function and functionality, easy to install in a 2 gang outlet box.

    Posted by Pedro on 13th Mar 2024

    Function and functionality, easy to install in a 2 gang outlet box.
